KT250_EN
| EAN code | 8595057600294 |
| Customs code | 85381000 |
| წონა | 0,6570 kg/ც |
| Material | PVC |
| Leadless material | yes |
| Self-extinguishing | 30 s |
| Rated voltage | <= 400 V |
| Rated current | <= 16 A |
| Temperature resistance | -5 - +60 °C |
| Flaming loop test | 850 °C |
| Width | 205 mm |
| Height | 255 mm |
| Depth | 66 mm |
| Fire reaction class of underlying material | A1 - D |
| Standards | ČSN EN 60 670-1 |
| Package description individual boxes with lids packed in shrink foil and provided with a label and placed in a carton | |
Boxes for communication and power distribution. At the bottom of the box are grooves for mounting the telephone terminals. Suitable for surface mounting - lid follows the size of the box. Boxes without preformed knockouts.
