KT250L_EN
| EAN code | 8595057618640 |
| Customs code | 85381000 |
| წონა | 0,56 kg/pcs |
| Material | PVC |
| Leadless material | yes |
| Self-extinguishing | 30 s |
| Rated voltage | <= 400 V |
| Rated current | <= 16 A |
| Temperature resistance | -5 - 60 °C |
| Flaming loop test | 850 °C |
| Width | 234 mm |
| Height | 176 mm |
| Depth | 79 mm |
| Milled (drilled) hole diameter | 40 mm |
| Manufactures´s recommendations For all range of products in hollow walls, we recommend using the milling sets supplied by us. | |
| Fire reaction class of underlying material | A1 - F |
| Protection types | IP 30 |
| Standards | ČSN EN 60 670-1 |
| Package description the screws for fixing the lid and the screws for fixing to plasterboard are installed in the box, individual boxes together with the lid are packed in shrink wrap | |
A large number of knockouts for inserting cables and pipes. Possibility to install the support trunking TS 35. Possibility to set the lid in a horizontal position. Possibility to break the sidewall for easier cable handling. Outer side of the bottom contains holes for marking drill holes. Mounting screws are fitted with a triple thread for quick installation. The IP30 protection complys a box fitted with a lid.
